Allen-Bradley 1734-AENTR Dual Ethernet POINT I/O Communication Module: A Comprehensive Overview

1. Introduction

The Allen-Bradley 1734-AENTR is a high-performance dual Ethernet communication module designed for industrial automation systems. As part of Rockwell Automation’s POINT I/O series, it serves as a critical interface between distributed I/O devices and Ethernet/IP networks, enabling seamless data exchange between field-level sensors, actuators, and central controllers such as PLCs, HMIs, and SCADA systems.

This module stands out for its robustness, flexibility, and support for advanced networking protocols, making it suitable for demanding applications in manufacturing, process control, energy management, and infrastructure sectors. Its dual Ethernet ports, embedded switching capabilities, and compatibility with multiple network topologies enhance system reliability and simplify installation.

2. Key Features

2.1 Dual Ethernet Connectivity

The 1734-AENTR features two independent 10/100 Mbps Ethernet ports with RJ-45 connectors, supporting both half-duplex and full-duplex communication. These ports function as embedded switches, allowing daisy-chaining (linear/菊花链), ring, star, or tree network topologies without requiring external switches. This redundancy improves fault tolerance, ensuring continuous operation even if one link fails.

2.2 EtherNet/IP Protocol Support

The module adheres to the EtherNet/IP standard, a widely adopted industrial Ethernet protocol. It enables real-time data transfer with low latency, critical for applications like motion control, robotics, and synchronized production lines. The module also supports CIP (Common Industrial Protocol), facilitating interoperability with other Allen-Bradley devices and third-party equipment.

2.3 Flexible IP Configuration

Users can assign IP addresses via three methods:

• Manual Setup: Using the module’s built-in pen-push rotary switches for quick static IP allocation.
• DHCP/BOOT-P: Dynamic IP assignment via network servers, ideal for large-scale deployments.
• Non-Volatile Memory: Retrieving pre-configured IP settings from internal storage.

Static IP is recommended for stability, while dynamic IP suits temporary or mobile setups.

2.4 High-Density I/O Expansion

As a POINT I/O adapter, the 1734-AENTR supports up to 63 modules (31 direct connections) per system, accommodating a mix of digital, analog, and specialty I/O types. This scalability reduces hardware costs and cabinet space compared to traditional distributed I/O solutions.

2.5 Diagnostic and Security Functions

• LED Indicators: Visual status alerts for power, network links, and communication errors.
• Built-in Diagnostics: Logs network faults, device disconnections, and data transmission issues for troubleshooting.
• Security: Supports ACL (Access Control Lists) and port security to prevent unauthorized access, protecting against cyber threats.

2.6 Environmental Robustness

• Operating Temperature: -20°C to +60°C (non-condensing), suitable for harsh industrial environments.
• Storage Temperature: -40°C to +85°C, ensuring reliability during transportation and long-term storage.
• Humidity Tolerance: 5% to 95% RH (non-condensing), resistant to moisture and dust.
• IP20 Rating: Protects against solid objects >12.5 mm, though not waterproof.

3. Technical Specifications

4. Applications

4.1 Industrial Automation

In manufacturing plants, the 1734-AENTR connects sensors, actuators, and motors to PLCs like the Allen-Bradley ControlLogix or CompactLogix series. For example, in automotive assembly lines, it monitors robot positions via digital inputs and triggers pneumatic tools through digital outputs, ensuring precise synchronization.

4.2 Energy Management

The module integrates with renewable energy systems (e.g., wind turbines, solar inverters) to monitor power output, grid stability, and environmental conditions. Its rugged design withstands temperature extremes and vibrations common in outdoor installations.

4.3 Marine Navigation

Certified by Registro Italiano Navale (RINA), the 1734-AENTR is deployed in shipboard navigation systems. It links GPS receivers, radar units, and compass modules to centralized control panels, enabling real-time route adjustments and collision avoidance.

4.4 Building Automation

In smart buildings, the module manages HVAC systems, lighting controls, and security sensors. For instance, it adjusts airflow based on occupancy data from motion detectors, optimizing energy efficiency while maintaining comfort.

5. Advantages Over Competitors

5.1 Cost Efficiency

The 1734-AENTR’s compact size and high I/O density reduce cabling and enclosure costs compared to larger distributed I/O systems. Its compatibility with POINT I/O modules allows incremental upgrades without full system overhauls.

5.2 Ease of Integration

Configured via RSLogix 5000 or Studio 5000 software, the module seamlessly integrates with Allen-Bradley controllers. Its support for DeviceNet and ControlNet (via firmware updates) ensures backward compatibility with legacy systems.

5.3 Reliability

Dual Ethernet ports and embedded switching eliminate single points of failure, while diagnostic tools minimize downtime. The module’s industrial-grade components resist shock, vibration, and electromagnetic interference (EMI).

6. Conclusion

The Allen-Bradley 1734-AENTR is a versatile, high-performance communication module that bridges the gap between field devices and Ethernet networks. Its dual-port design, support for multiple topologies, and robust diagnostic capabilities make it indispensable for modern industrial automation. Whether deployed in factories, power plants, or marine vessels, the 1734-AENTR delivers reliable, cost-effective connectivity, ensuring seamless data flow in mission-critical applications.

For organizations seeking to optimize their control systems, the 1734-AENTR represents a future-proof investment, combining scalability, security, and ease of use in a single package.
